5400 OLP Air/Water Reel

TH5400 OMP – 1/4 in. x 25 ft. Twin Hydraulic Hose Reel

The hydraulic series hose reel incorporates contemporary engineering and manufacturing techniques to give a trouble-free performance. Used for medium pressure hydraulic applications, Series TH hose reels are ideal for operating hydraulic cylinders, tools, and equipment. Reels are all-steel construction and compact for applications with critical space requirements.

  • Quality finish and corrosion resistant – Individually powder coated components offer the maximum protection from premature corrosion.
  • Long-life drive spring – Declutching arbor virtually eliminates the possibility of spring damage due to reverse winding. Only the highest quality spring steel is used and conditioned to ensure there are no imperfections offering maximum service life.
  • Constant tension or pos-i-latch spool mechanism
  • Compact design for critical space requirements

*Reel is shipped in the top wind position. The reel image is shown in the side wind position.

SKU: TH5400 OMP Category:

Reel Specifications and Dimensions

Additional information

Weight24 lbs
Series

Hose I.D.

Hose O.D.

Hose Length

Pressure

Inlet

Reel Outlet

Hose Included

Max Temperature

UPC

699567003496

A14.375"
B14.25"
C9.75"
D2.5"
E6.125"


Fluid Path Materials

Internal Fluid PathSteel
Swivel AssemblySteel
Swivel SealBuna


Literature and Service Manual

FAQs

How do I increase or reduce spring tension?

Can I adjust the guide opening position on an enclosed model hose reel?

Can my spring driven reel be made constant tension?

How do I install a new drive spring and set pre-turns?

How many GPM’s will I get from my hose?

Air pressure or fluid flow restricted

Hose or cord will not retract

Material leaking from swivel

Reel will not latch
